cyber® simco® drive 2 – servo drive

  • Servo controller cyber® simco® drive 2 for use in control cabinet or decentralized

  • cyber® simco® drive 2 IP20: perfect fit for use in control cabinets

  • cyber® simco® drive 2 IP65: decentral drive concept for use in the machine surroundings

  • Small servo drive system: cyber® simco® drive 2, cyber® dynamic system and cyber® dynamic line

  • Software MotionGUI 2: technology function for programming applications

  • Software MotionGUI 2: Analysis of applications and movement sequences via the SCOPE function

connective – intelligent – safe

In combination with various servo motors and servo actuators, cyber® simco® drive 2 is the ideal solution for fast and precise moving and positioning tasks. With a continuous output of up to 750 W and a short-term peak output of 1,5 kW, the servo drive is suitable for high-precision applications, e.g. in the machine-tool, electronics or packaging industries – as a switch cabinet version with protection class IP20 or decentralized version with protection class IP65.

Whitepaper: Recommendations for the deployment of third-party servo drives with EtherNet/IP CIP SyncTM

Machine manufacturers from different industrial segments have high standards for dynamic and precise motion control applications in real-time. By integrating CIP SyncTM in third-party servo drives, it is possible to meet these requirements. Read our whitepaper to learn more about the possibilities and advantages.

Request now

Excellent solution for complex motion tasks

Connectivity

  • Multi-Ethernet version
  • Many real-time capable fieldbus interfaces
  • Various encoder interfaces

Intelligence

  • Automatic parameterization thanks to electronic name plate
  • Integrated PLC functionality

Safety and robustness

  • Integrated safety function STO according to SIL3 / PL e
  • 12 to 60 VDC wide range input
  • Protection class up to IP65

Flexibility

  • Multi-Ethernet version
  • Different performance classes
  • Flexible programming of motion tasks
  • Protection class IP20 and IP65

Easy installation and commissioning

  • Compact design
  • Connection elements arranged in the front allow simple pin assignment
  • Stackability

Dynamics and precision

  • Real-time capable and isochronous Ethernet communication
  • High current resolution of 14 bits for high-precision torque control
  • Switching frequency of 16 kHz

Product highlights

The cyber® simco® drive 2 range includes servo drives for sine-commutated servo motors in the voltage range from 12 to 60 VDC and a maximum power up to 1,5 kW. The servo drives are available as control cabinet variant or in a decentralized design with protection rating IP65. In combination with the intuitive MotionGUI 2 software, simple parameterization, commissioning and optimization of the system as well as flexible programming of applications is possible (Sercos and CANopen on request).

Space-saving installation thanks to stackability and user-friendly pin assignment

Extremely compact: up to 30% installation space saving

Numerous fieldbus interfaces and decentral intelligence

Simple installation in the machine without enclosure thanks to protection class IP65

Safe shutdown of the system in case of emergency thanks to integrated STO (Safe Torque Off) safety function to SIL3 without loss of productivity

Electronic type plate enables automatic and safe parametrization of the motor

High precision and dynamic torque control to achieve higher machine output
